Polish Orthopedics and Traumatology, 2014; 79: 45-46
We read with great interest ‘‘Technical tip: Tightrope fixation of neer type II distal clavicle fracture supported by a case series.’’ by Haque et al. [1].
The treatment modalities of this type fractures are still controversial in literature. No consensus has been reached in the operative managment of these fractures. Proposed treatments have included coracoclavicular screws, kirchner wires with tension bands,coracoclavicular fixation with tight ropes or suture anchors,clavicular hook plates,locked plates or some combinations. Despite the authors discussed and compared mostly used three techniques (clavicular hook plate,coracoclavicular screw fixation, intramedullary stabi- lization)with their own technique, the recent literature offers another alternative technique. Madsen W. et al. [2], Bishop J.Y. [3] and Rieser G.R. et al. [4] performed biomechanical study at cadaver models which offers an additional suture anchor fixation to coracoclaviculer area with precountered distal clavicle locking plate.This additional fixation offered increasing vertical stability. Also Andersen J.R. et al. [5], Herrmann S. et al. [6], Klein S.M. et al. [7], Bhatia D.N. et al. [8] and Johnston P.S. et al. [9] reported the supeority of this method in their clinical series. Therefore we could easily say that in the literature this combination of locking plate with coracoclavicular suture anchor fixation technique rarely reported.
We agree with the group who supports the usage of anatomic locking distal clavicla plate augmented with suture anchor fixation.This method allows an anatomic reduction with bone-bone contact and gives additional neutralisation effect with coracoclavicular suture anchor fixation against the trapezius muscle pulling effect.Event though the ef- feciency of this technique reported by other authors,still there is a few articles and cases reported. In the terms of proving the efficiency of the combination technique and contribution to the literature we would like share the preoperative and postoperative x-rays of our case which proves excellent result.
Acknowledgements
The authors would like to thank Antalya Memorial Hospital chief of medicine Dr Sevim Suekinci for providing the necessary settings for the study. The junior authors also would like to thank our senior author Ahmet Turan Aydin for his exceptional skills and devoted personality.
Pismiennictwo:
- Haque S, Khan A, Sharma A, Sundararajan S: Technical tip: Tightrope fixation of neer type II distal clavicle fracture supported by a case series. Pol Orthop Traumatol, 2014; 79: 19-22
- Madsen W, Yaseen Z, LaFrance R et al: Addition of a suture anchor for coracoclavicular fixation to a superior locking plate improves stability of type IIB distal clavicle fractures. Arthroscopy, 2013; 29(6): 998-1004
- Bishop JY, Roesch M, Lewis B et al: A biomechanical comparison of distal clavicle fracture reconstructive techniques. Am J Orthop (Belle Mead NJ), 2013; 42(3): 114-18
- Rieser GR, Edwards K, Gould GC et al: Distal-third clavicle fracture fixation: a biomechanical evaluation of fixation. J Shoulder Elbow Surg, 2013; 22(6): 848-55
- Andersen JR, Willis MP, Nelson R, Mighell MA: Precontoured superior locked plating of distal clavicle fractures: a new strategy. Clin Orthop Relat Res, 2011; 469(12): 3344-50
- Herrmann S, Schmidmaier G, Greiner S: Stabilisation of vertical unstable distal clavicular fractures (Neer 2b) using locking T-plates and suture anchors. Injury, 2009; 40(3): 236-39
- Klein SM, Badman BL, Keating CJ et al: Results of surgical treatment for
unstable distal clavicular fractures.J Shoulder Elbow Surg, 2010; 19(7): 1049-55
- Bhatia DN, Page RS: Surgical treatment of lateral clavicle fractures associated with complete coracoclavicular ligament disruption: Clinico- radiological outcomes of acromioclavicular joint sparing and spanning implants. Int J Shoulder Surg, 2012; 6(4): 116-20
- Johnston PS, Sears BW, Lazarus MR, Frieman BG: Fixation of Unstable Type II Clavicle Fractures with Distal Clavicle Plate and Suture-button. J Orthop Trauma, 2014; [Epub ahead of print]
